MNT Pocket Reform USB Standalone Keyboard

Equipped with a micro-optical trackball, the MNT Pocket Reform Standalone Keyboard makes for a comfy couch or desk setup that doesn't require a mouse.

Derived from our original Pocket Reform mini laptop, this anthracite keyboard embraces all the features that have made the typing experience so satisfying: the iconic mini trackball, the mechanical keyboard, the ortholinear layout, the practical OLED screen, and the customizable RGB backlight.

Small in size and light in weight, the Pocket Reform Standalone Keyboard is an ideal fit for cluttered desk spaces, browsing the internet (or watching movies) on the couch, coding, reading (or writing) papers, communicating with your peers.

Connecting it to a tablet or phone via USB-C cable makes this keyboard an excellent on-the-go typing alternative to a touch screen.

Main Benefits

Open Hardware

All sources public
Modifiable & reproducible
Active community

Keycaps

QWERTY-US layout
Dimmable RGB backlight
Ortholinear

Switches

Mechanical & ergonomic
Kailh Choc switches
Linear, tactile, or clicky

Detailed Specs

Designed by Ana Dantas, the repairable case is made from 2 parts:
- Nylon, HP Multi Jet Fusion (Grey, lightweight)
- Black anodized, bead blasted aluminum top plate
RGB backlight, 64 individually addressable LEDs
High resolution 15 mm optical trackball (Material: POM/Acetal) with 4 buttons (Left, Middle, Right, X/Y Scroll)
64 Kailh Choc low-profile mechanical key switches
- Red Pro (linear)
- White (clicky)
- Brown (tactile)
Laser engraved, injection molded translucent ABS/black PU MNT Pocket keycaps
Customizable monochrome 128x64 pixel OLED display with settings menu
RP2040 Controller
Single USB-C connector for USB HID and Power
Repairable and modifiable: see PCBA options (without case) here

In the Box

MNT Pocket Reform Standalone Keyboard (fully assembled)
USB-C Cable not included
Dimensions: 20.5 cm x 13 cm x 2.5 cm

Support

Manual and Downloads
For questions, updates and feedback, join the MNT Community or contact our customer support.
Head over to our FAQs if you have any questions regarding payment methods, import fees and warranty.
